C10300 C10200 Pure Red 4x8 Copper Sheet Construction Grade Sheet
Product Specifications
| Attribute |
Value |
| Material |
Red copper |
| Alloy |
Non-alloy |
| Color |
Red |
| Length |
10~12000mm, as Required |
| Width |
10mm~2500mm |
| Technique |
Cold Rolled |
| Hardness |
Soft, 1/2 Hard, 1/4hard, Hard |
| Application |
Electrical Semiconductor Chemical Building |
Premium Pure Copper Sheet for Industrial & Construction Applications
Our C10200 & C10300 Pure Red Copper Plate is a high-performance construction-grade material manufactured to meet JIS H3250-2006, ASTM B152M, and GB/T2040-2008 standards. With 99.9% minimum copper purity, this 4x8 ft (1220x2440mm) sheet offers exceptional electrical conductivity, thermal efficiency, and corrosion resistance, making it ideal for building construction, electrical systems, and industrial machinery.
Key Features
- Ultra-High Purity (Cu ≥99.9%) - Superior conductivity for electrical & thermal applications
- Standard 4x8 ft Size - Ready for construction & fabrication use
- Multiple Hardness Options - Soft, 1/4 Hard, 1/2 Hard, Full Hard
- Corrosion-Resistant - Long lifespan in harsh environments
- Custom Processing - Cutting, welding, punching, and surface finishing available
Detailed Specifications
| Parameter |
Details |
| Material Grades |
C10200, C10300, C10100-C12500 |
| Standards |
JIS H3250-2006, ASTM B152M, GB/T2040-2008 |
| Purity |
≥99.9% Cu (Oxygen-Free Available) |
| Thickness |
0.1mm-500mm (Standard: 0.5mm-6mm) |
| Width |
10mm-2500mm (Standard: 1220mm / 4ft) |
| Length |
Custom up to 12m (Standard: 2440mm / 8ft) |
| Hardness |
Soft, 1/4 Hard, 1/2 Hard, Full Hard |
| Surface Finish |
Mill, Polished, Brushed, Mirror, Oiled |
| MOQ |
1 Ton (Small samples available) |
| Delivery Time |
7-15 days (Express options available) |
| Certifications |
ISO 9001, RoHS, IBR |
Applications
- Electronics & Semiconductors - PCB substrates, connectors, transformers, and shielding components.
- Construction & Architecture - Decorative cladding, roofing, and anti-corrosion layers.
- HVAC & Refrigeration - Heat exchangers, condenser plates, and cooling systems.
- Industrial Machinery - Bearings, bushings, and high-conductivity mechanical parts.
- Chemical & Medical Equipment - Corrosion-resistant tanks, lab instruments, and piping.
- Renewable Energy - Solar panel conductive layers, battery terminals, and wind turbine components.
Why Choose Our Red Copper Sheets?
- Certified Quality - Meets JIS, ASTM, and GB standards
- Custom Sizes & Finishes - Cut-to-size, polished, or coated surfaces
- High Conductivity - Ideal for electrical & thermal applications
- Global Supply - Exported to USA, Europe, Middle East, and Asia
- Competitive Pricing - Factory-direct rates with bulk discounts
Frequently Asked Questions
Q1: What's the difference between C10200 and C10300 copper?
C10200 (Oxygen-Free Copper) - 99.95% purity, best for high-vacuum & electrical uses
C10300 (Phosphorus-Deoxidized Copper) - Improved weldability for plumbing & HVAC
Q2: Can I get a custom-cut size instead of 4x8 ft?
Yes! We provide laser/waterjet cutting for any required dimensions.
Q3: Is this copper sheet suitable for outdoor use?
Absolutely—its natural corrosion resistance makes it perfect for roofing & marine applications.
Q4: What's the lead time for 5-ton orders?
10-12 days after deposit confirmation (faster shipping available).
Q5: Do you provide material certifications?
Yes, we supply Mill Test Reports (MTR), ISO 9001, and RoHS compliance.
